LUXEON CZ Color Line 是具有先进光学性能的彩光和白光 LED 系列。LUXEON CZ Color Line 可实现最佳的照明效果,是建筑、娱乐及应急车辆照明应用的最佳 LED 解决方案。
LUXEON CZ Colors product performance at 350mA,Tj=85°C.
COLOR |
DOMINANT OR PEAK WAVELENGTH (nm) |
LUMINOUS FLUX (lm) OR RADIOMETRIC POWER (mW) |
PART NUMBER | ||
---|---|---|---|---|---|
MINIMUM | MAXIMUM | MINIMUM | TYPICAL | ||
Far Red | 720 | 750 | 150 | 200 | L1CU-FRD1000000000 |
Deep Red | 655 | 675 | 190 | 225 | L1CU-DRD1000000000 |
Red | 624 | 634 | 20 | 31 | L1CU-RED1000000000 |
Red-Orange | 614 | 624 | 25 | 37 | L1CU-RNG1000000000 |
Amber | 585 | 600 | 10 | 16 | L1CU-AMB1000000000 |
PC Amber | - | - | 65 | 78 | L1CU-PCA1000000000 |
Mint | - | - | 120 | 132 | L1CU-MNT1000000000 |
Lime | - | - | 120 | 122 | L1CU-LME1000000000 |
Green | 520 | 540 | 80 | 99 | L1CU-GRN1000000000 |
Cyan | 490 | 510 | 60 | 73 | L1CU-CYN1000000000 |
Blue | 465 | 485 | 25 | 33 | L1CU-BLU1000000000 |
Royal Blue | 440 | 460 | 360 | 425 | L1CU-RYL1000000000 |
Violet | 420 | 430 | 400 | 458 | L1CU-VLT1000000000 |
